Description
The MSI X870E GAMING PLUS WIFI AM5 DDR5 ATX Motherboard is based on the AMD X870E chipset for compatible Ryzen 9000, 8000 and 7000 Series processors. It combines DDR5 memory, PCIe 5.0 graphics and M.2 storage, 5Gb LAN, Wi-Fi 7 and high-speed USB Type-C connectivity in an ATX design.
MSI X870E GAMING PLUS WIFI AM5 DDR5 ATX Motherboard Specifications and Features
Key Features
- AMD X870E Platform – Supports AMD Ryzen 9000, 8000 and 7000 Series processors on Socket AM5.
- DDR5 Capacity – Four DIMM slots support up to 256GB with AMD EXPO profiles.
- PCIe 5.0 Graphics – The primary x16 slot supports PCIe 5.0 for compatible processor configurations.
- Gen5 M.2 Storage – Three M.2 sockets include one PCIe 5.0 x4 slot and two PCIe 4.0 x4 slots.
- 5Gb LAN and Wi-Fi 7 – Realtek 5Gb LAN, Wi-Fi 7 and Bluetooth 5.4 provide high-speed wired and wireless connectivity.
- USB 40Gbps Type-C – Rear I/O includes a USB 40Gbps Type-C port.
Technical Specifications
| Specification | Details |
|---|---|
| Product Name | MSI X870E GAMING PLUS WIFI |
| CPU Socket | AMD Socket AM5 |
| Supported Processors | AMD Ryzen 9000 / 8000 / 7000 Series |
| Chipset | AMD X870E |
| Memory | 4 x DDR5 DIMM, up to 256GB |
| Memory Profile | AMD EXPO |
| Primary Expansion | PCIe 5.0 x16 with supported processor configurations |
| M.2 Storage | 3 x M.2: 1 x PCIe 5.0 x4 and 2 x PCIe 4.0 x4 |
| SATA | 4 x SATA 6Gb/s |
| Ethernet | Realtek 5Gb LAN |
| Wireless | Wi-Fi 7; Bluetooth 5.4 |
| Display Output | HDMI 2.1; USB4 Type-C with DisplayPort support |
| Audio | Realtek ALC897, 7.1-channel High Definition Audio |
| Rear USB | Includes USB 40Gbps Type-C and USB 20Gbps Type-C |
| Form Factor | ATX, 243.84 x 304.8 mm |
